The Mile Marker SEC8 is a no-frills, down-to-business winch with 8,000 pounds of pulling power. Boasting blazing line speeds, a high output 4.9 HP series wound motor, and an automatic load-holding brake system, this is the essential winch for overland explorers and competition rigs seeking to quench their adventurous thirst as they traverse the globe’s harshest conditions. Built with marine-grade remote control connectors and fully-sealed, submersible, water, mud, and snow proof, each SEC8 comes with a 5/16” x 100’ steel cable, a roller fairlead, stainless steel hardware, corrosive-resistant, a hook, and a handheld remote control with a 12′ cord.

FEATURES:

• 4.9 HP Series Wound Motor
  Rugged Planetary Gear Sets
• Clockable Gear Housing
• Fast Line Speeds
• Submersible, 400 Amp Solenoid
• Automatic Load-Holding Brake
• Corrosion Resistant Stainless Steel Fasteners
• 100′ Steel Cable
• Roller Fairlead
• Waterproof
• Handheld Remote control

SPECIFICATIONS:

• Part Number 77-50141W
• Rated line pull 8000 lbs (3629 Kg)
• Gear Train 3 Stage Planetary
• Gear Ratio 150:1
• Motor Series Wound, 4.9 hp (3.6 kW), 12 v
• Remote Control Power-In, Power-Out Remote, 12’ (3.7 m)
• Dimensions (LxWxH) 21.50” X 6.25” X 8.00” (546.1 mm X 158.8 mm X 203.2 mm)
• Steel Cable 5/16” X 100’ (nominal 9,800 lbs, 4445 kg) (7.94 mm X 30.5 m)
• Drum Size 2.5” X 9” (63.5 mm X 228.6 mm)
• Net weight 81 lbs (37 kg) Bolt Pattern 4
• Bolt Pattern, 4.5” X 10”, (114.3 mm X 254 mm)
